Part Number:IST-PS42A

Dimension:41.8 * 16mm

Rated Voltage:12VDC

Resonant Frequency:2800±500Hz

SPL:≥105dB@10cm

Current:≤10mA

Operating Voltage:3~20VDC

Part Number:IST-PS23B

Dimension:22.5 * 12.0mm

Rated Voltage:12VDC

Resonant Frequency:3300±500Hz

SPL:≥95dB@10cm

Current:≤12mA

Operating Voltage:1.5~24VDC

Part Number:IST-PS14A

Dimension:13.8 * 7.5mm

Rated Voltage:12VDC

Resonant Frequency:4000±500Hz

SPL:≥85dB@10cm

Current:≤7mA

Operating Voltage:3~25VDC

Part Number:IST-S43A

Dimension:43.0 * 53.0mm

Rated Voltage:220VDC

Resonant Frequency:2800±500Hz

SPL:≥91dB@60cm

Current:≤16mA

Operating Voltage:60~250VDC

Part Number:IST-PS45A

Dimension:45.0 * 26.0mm

Rated Voltage:12VDC

Resonant Frequency:2900±500Hz

SPL:≥100dB@10cm

Current:≤35mA

Operating Voltage:3~18VDC

Part Number:IST-PS23A

Dimension:23.0 * 10.0mm

Rated Voltage:12VDC

Resonant Frequency:3500±500Hz

SPL:≥90dB@10cm

Current:≤15mA

Operating Voltage:3~20VDC

Part Number:IST-PS30H

Dimension:29.5 * 24.5mm

Rated Voltage:24VDC

Resonant Frequency:3500±500Hz

SPL:≥100dB@30cm

Current:≤30mA

Operating Voltage:3~28VDC

Part Number:IST-PS42B

Dimension:41.7 * 18.0mm

Rated Voltage:12VDC

Resonant Frequency:3500±500Hz

SPL:≥85dB@10cm

Current:≤25mA

Operating Voltage:5~18VDC

Part Number:IST-PS22A

Dimension:22.0 * 10.7mm

Rated Voltage:5VDC

Resonant Frequency:4000±500Hz

SPL:≥90dB@10cm

Current:≤10mA

Operating Voltage:≤20VDC

Part Number:IST-PS30F

Dimension:30.0 * 14.0mm

Rated Voltage:12VDC

Resonant Frequency:3100±500Hz

SPL:≥85dB@10cm

Current:≤50mA

Operating Voltage:5~14VDC
