Focus on R&D, production and sales

A manufacturing enterprise for all kinds of electroacoustic components

Part Number:ISTW-A1440H09TR

Dimension:14 * 9MM

Construction:Enclosed

Directivity:X:110°±15° Y:60°±15°

SPL:≥90dB (10cm/10Vrms Sine Wave)

Sensitivity:≥-70dB

Nominal Frequency:40±1.5KHz

Using Method:Dual use

Part Number:ISTW-A1440H09TR-W

Dimension:14 * 9MM

Construction:Enclosed

Directivity:X:120°±15° Y:65°±15°

SPL:≥96dB (10cm/10Vrms Sine Wave)

Sensitivity:≥-74dB

Nominal Frequency:40±1.5KHz

Using Method:Dual use

Part Number:ISTW-A1840H12TR

Dimension:18 * 12MM

Construction:Enclosed

Directivity:60°±15°(-6dB)

SPL:≥96dB (10cm/10Vrms Sine Wave)）

Sensitivity:≥-74dB

Nominal Frequency:40±1.5KHz

Using Method:Dual use

Part Number:ISTW-A1458H09TR-W

Dimension:14 * 9MM

Construction:Enclosed

Directivity:X:115°±15° Y:65°±15°

SPL:≥85dB （10mm/10Vrms sine wave）

Sensitivity:≥-74dB

Nominal Frequency:58±1.5KHz

Using Method:Dual use

Part Number:ISTW-A1640H09TR

Dimension:16 * 9MM

Construction:Enclosed

Directivity:X:120°±15° Y:60°±15°

SPL:≥100dB (10cm/10Vrms Sine Wave)

Sensitivity:≥-82dB

Nominal Frequency:40±1.5KHz

Using Method:Dual use

Part Number:ISTW-A1640H10TR

Dimension:16 * 10MM

Construction:Enclosed

Directivity:80±10°

SPL:≥96dB (10cm/10Vrms Sine Wave)

Sensitivity:≥-74dB

Nominal Frequency:40±1.5KHz

Using Method:Dual use

Part Number:ISTW-A1640H12TR

Dimension:16 * 12MM

Construction:Enclosed

Directivity:X:80°±15° Y:80° ±15°

SPL:≥100dB (10cm/10Vrms Sine Wave)

Sensitivity:≥-85dB

Nominal Frequency:40±1.0KHz

Using Method:Dual use
