Focus on R&D, production and sales

A manufacturing enterprise for all kinds of electroacoustic components

Part Number:IST-05ET02A

Dimension:5.0* 5.0 * 2.0mm

Rated Voltage:3Vp-p

Resonant Frequency:4000±500Hz

SPL:≥75dB@10cm

Current:≤110mA

Operating Voltage:2~4Vp-p

Part Number:IST-10ET03A

Dimension:10.0 * 10.0 * 3.2mm

Rated Voltage:3.6Vp-p

Resonant Frequency:2830±500Hz

SPL:≥ 85dB@10cm

Current:≤90mA

Operating Voltage:2-5Vp-p

Part Number:IST-05ET03A

Dimension:5.0 * 5.0 * 3.0mm

Rated Voltage:5Vp-p

Resonant Frequency:4000±500Hz

SPL:≥75dB@10cm

Current:≤110mA

Operating Voltage:4~7Vp-p

Part Number:IST-07ET03A

Dimension:7.5 * 7.5 * 2.5mm

Rated Voltage:3.6Vp-p

Resonant Frequency:2731±500Hz

SPL:≥80dB@10cm

Current:≤100mA

Operating Voltage:2.5~4.5Vp-p

Part Number:IST-13ES10A

Dimension:12.8 * 12.8 * 10.0mm

Rated Voltage:5VDC

Resonant Frequency:2400±500Hz

SPL:≥85dB@10cm

Current:≤30mA

Operating Voltage:4~7VDC

Part Number:IST-08ET04A

Dimension:8.5 * 8.5 * 4.0mm

Rated Voltage:3.6Vp-p

Resonant Frequency:2730±500Hz

SPL:≥85dB@10cm

Current:≤100mA

Operating Voltage:2.5~4.5Vp-p

Part Number:IST-08ET03A5V

Dimension:8.5 * 8.5 * 3.0mm

Rated Voltage:3.6Vp-p

Resonant Frequency:2731±500Hz

SPL:≥86dB@10cm

Current:≤100mA

Operating Voltage:2.5~4.5Vp-p

Part Number:IST-04ET02A

Dimension:4.0 * 4.0 * 2.0mm

Rated Voltage:3Vp-p

Resonant Frequency:4000±500Hz

SPL:≥70dB@10cm

Current:≤90mA

Operating Voltage:2~4Vp-p

Part Number:IST-09ES05A

Dimension:9.6 * 9.6 * 5.5mm

Rated Voltage:3Vp-p

Resonant Frequency:2700±300Hz

SPL:≥85dB@10cm

Current:≤30mA

Operating Voltage:2.5~4.5Vp-p

Part Number:IST-09ET04A

Dimension:9.0 * 4.0mm

Rated Voltage:3.6Vp-p

Resonant Frequency:2730±500Hz

SPL:≥85dB@10cm

Current:≤100mA

Operating Voltage:2.5-4.5Vp-p
