Focus on R&D, production and sales

A manufacturing enterprise for all kinds of electroacoustic components

Part Number:IST-MB26A04W12

Dimension:26 * 17.7mm

Rated Voltage:12VDC

Resonant Frequency:400±100Hz

SPL:≥75dB@10cm

Current:≤25mA

Operating Voltage:8~15VDC

Part Number:IST-MB23A

Dimension:23 * 14mm

Rated Voltage:12VDC

Resonant Frequency:400±100Hz

SPL:≥75dB@10cm

Current:≤25mA

Operating Voltage:8~15VDC

Part Number:IST-MB33A

Dimension:23 * 17MM

Rated Voltage:1.5VDC

Resonant Frequency:400±100Hz

SPL:≥70dB@20cm

Current:≤20mA

Operating Voltage:1.3~2VDC

Part Number:IST-MB40A

Dimension:26 * 19.5mm

Rated Voltage:6VDC

Resonant Frequency:400±100Hz

SPL:≥95dB@10cm

Current:≤65mA

Operating Voltage:4~8VDC

Part Number:IST-MB50X10S

Dimension:27.2 * 16.1mm

Rated Voltage:12VAC

Resonant Frequency:100±20Hz

SPL:≥90dB@10cm

Current:≤250mA

Operating Voltage:8-16VAC

Part Number:IST-MB23B120V

Dimension:22.8*17.8mm

Rated Voltage:120VDC

Resonant Frequency:50±12Hz

SPL:≥80dB@10cm

Current:≤40mA

Operating Voltage:8~15VDC
